AR Blue Clean AR630 Gen 1 Maintenance Kit | Pump Oil and Water Seals

Your pressure washer needs maintenance just like your car. These are the 2 most common items we sell for the First Generation AR30TSS cold water model,

This is the suggested replacement water seal kit for the standard first generation AR630TSS model we offer (not the hot water version)

The AR2520 Water Seal Kit is the Original Equipment AR replacement Seal Kit. This AR2520 Water Seal Kit consists of the following parts:
3 x AR1260140 Support Ring Reducer Brass
3 x AR1260141 Support Ring Reducer Plastic
3 x AR1520120 Support Ring
3 x AR1271650 High Pressure Packing
3 x AR1260420 O-Ring
3 x AR1260440 Low Pressure Seal

The AR2520 was used on the Annovi Reverberi XT, XTA, XTV series pressure washer pumps also known as AR pumps and replaced old part # AR1866.

For AR630 Models the pump oil capacity is 5.5 ounces.

To change the oil, you will remove the plug that is on the bottom of the pump. You will need a 13mm socket to remove the plug.

Once the oil has been drained reinstall the plug and fill the pump up with new oil.
